AUTEL MaxiSys MS906BT Advanced Wireless Android Diagnostic & ECU Coding Tool Full System Scan

MaxiSys MS906BT is the latest addition to the MaxiSys product line of advanced wireless diagnostic devices. The device is based on the Android operating system featured with the best possible coverage of OE-level diagnostics and ECU coding capability. Utilizing the powerful Exynos 5260 6-core processor (1.3 GHz quad-core ARM Cortex-A7 + 1.7 GHz dual-core ARM Cortex-A15), an 8” capacitive HD touch screen, and long-distance wireless communication, the MaxiSys MS906BT efficiently provides comprehensive vehicle diagnostics and analysis.

AUTEL MaxiSys MS906BT Advanced Wireless Android Diagnostic & ECU Coding Tool Full System Scan

MaxiSys MS906BT Scanner Features:
*Extraordinarily powerful Samsung Exynos Hexa-core processor
*8.0” 1024×768 LED-backlit glossy Multi-Touch capacitive display with IPS technology for ultra-mobility
*Internal reliable 32GB SSD for better performance
*Built-in 8-megapixel rear camera with autofocus and flashlight
*802.11b/g/n Wi-Fi to access your favorite web resources
*Unique ergonomic design with rubberized outer protection and a rugged internal housing
*Built-in rechargeable lithium-polymer battery for up to 14 hours of continuous operation
*USB, audio and auxiliary ports make it easy to connect accessories
*Open source Android Operating System for fast boot-up and multitasking
*Easy and intuitive navigation makes finding what you need simple and fast
*The most extensive complete system coverage for more than 80 US, Asian and European makes and models
*Exceptional OE-Level functionality from comprehensive OBDII diagnostics & services to advanced ECU coding
*Complete capabilities for codes, live data, active test, ECU information, adaptation, matching, coding etc.
*Smart AutoVIN technology for identifying vehicle easily
*Automatic system and software updates with real-time push message notifications via internet
*Instant remote control tech support anytime, anywhere
*Cloud-based MaxiFix online community provides a vast database of diagnostic and repair tips and proven filed fixes
*Interactive Data Logging sessions enable direct contact with Autel Technical Support for first-hand troubleshooting of diagnostic bugs and errors
*One-stop multitasking designed for ideal management of workshop operations to keep all data files, customer info, and vehicle records well organized
*Enhanced wireless BT connectivity between the display tablet and VCI device allows greater mobility and ease at work
*Convenient data management system for managing internal program applications and reviewing data

Autel MS906BT Scanner Functions:
1.Diagnostic functions:

Full system diagnositc functions, Read/erase codes, Live data, ECU informaiton, Active test, freeze frame data, I/M reainess status, Vehicle information, O2 monitor test, on-board monitor test, component test, modules present, DTCs help.

2.Service Functions
Reset and install service intervals
Reset the oil change calculator in the engine and automatic transmission
Replacement of brake pads on vehicles with an electric parking brake
Adaptation of the sensor to the angular position of the steering wheel
Regeneration of Diesel particulate filter
Bleeding brake system with ABS, etc.
Immobilizer functions
Battery Registration and reset

3.Special Tests

The actuators are not always visually visible or too complex to assess their performance with organoleptic (eyes, ears) methods through normal activation. That’s why the test-components are implemented in MaxiSys scanners. Test-components will allow you to include special test modes in the computer, in which the electronic system itself creates conditions for verification and evaluates its results with further recommendations to the expert.

4.Adaptation and Initialization

After replacement, for repair or cleaning of some sensors and many actuators of electronic systems, an adaptation or initialization procedure is required. When performing this procedure, the basic values of their work, the reference point, are established. In a modern car, there are many such elements that require similar procedures, which makes these functions vital for the service. In MaxiSys systems, these procedures are presented at the dealer level.

5.ECU Coding

Coding functions are usually used by advanced specialists. Coding is conditionally divided into two types:
The first is the computer coding during replacement, commissioning, used to install a new computer in the car. When performing the procedure, the computer is informed of vehicle’s VIN, the configuration and other information necessary for correct operation.
The second is the coding of the computer for tuning the body electronics to the user, usually the BCM. The procedure will allow you to offer the customer individual customization of the car for him, locking the doors, setting alarms, the function “lead to home”, setting the salon and outdoor lighting, etc.

Auto VIN Technology

Supported Hardware:

The MaxiSys MS906BT can work with the Autel inspection camera (such as MV105,MV108) and the Oscilloscope (MaxiScope MP408)

Entertainment

Autel MS906BT Scanner Specifications:

MaxiSys MS906 BT Scanner Supported Vehicle List:

Autel MaxiSys MS906 vs. MS906 TS vs. MS906 BT vs. MaxiSys

The main difference between the MS906BT and the DS808

MS906BT communicates with the car via Bluetooth communication (DS808 is hardline)
MS906BT comes with a full kit of OBDI cables for the older models
MS906BT gets software updates (specifically coding updates) earlier then DS808.
The software of the DS808 and MS906BT is very similar. So the DS808 is a great value for money option, but if you want all the bells and whistles, the Autel MS906BT is the way to go.

The main difference between the MS906BT and the MS908P

The Autel MS908P can perform flashing/reprogramming – newer vehicles have more onboard computers (ECM & TCM) that are programmed with thousands of parameters (control spark, fuel, idle etc).
Updating this software normally requires the car to be sent to dealers
Replacing new parts or changing existing parameters on many of the new vehicles requires flash reprogramming
Autel provides their own server for BMW & BENZ software (free as long as you are active on updates). All other OEM flashing software can be purchased separately and used with the MS908P VCI device.

MaxiSys MS906BT Package including:
User Manual
Carrying Case
Adaptor for Chrysler-16 (for NA only)
Light Fuse
MaxiVCI V100
Quick reference guide
Adaptor for GM/Daewoo-12
Adaptor for BMW-20
Adaptor for Benz-38
Adaptor for Kia-20
Adaptor for Mitsubishi/Hyundai-12+16
Adaptor for Nissan-14
Adaptor for Honda-3
Cigarette Lighter
Compact Disc (CD)
AC/DC External Power Adapter
Adaptor for VW/AUDI-2+2
Soft Cloth
Mini USB Cable
